F800 F1000 Drilling Rig Mud Pump
Bomco F800 f1000 drilling rig mud pump,Type:F serial pump, Triplex single acting,Pressure:High pressure,Model Number:F800 F1000 F1300 F1600,Application:oil drilling mud pump,After-sales Service Provided:Video technical support,$15,000.00 – $150,000.00/ Set|1 Set/Sets(Min. Order)
Bomco F800 f1000 drilling rig mud pump
Model | F-500 | F-800 | F-1000 | F-1300 | F-1600 |
Type | Triplex single acting | Triplex single acting | Triplex single acting | Triplex single acting | Triplex single acting |
Rated Power | 373kw | 596kw | 735kw | 969kw | 1193kw |
Rated Speed | 165 SPM | 150 SPM | 140 SPM | 120 SPM | 120 SPM |
Stroke(mm/inch) | 190/7 1/2 | 228.6/9 | 254/10 | 305/12 | 305/12 |
Max.Liner Dia. | 170/6 3/4 | 170/6 3/4 | 170/6 3/4 | 180/7 | 180/7 |
Gear Type | Herringbone | Herringbone | Herringbone | Herringbone | Herringbone |
Valve Pot | API-5 | API-6 | API-6 | API-7 | API-7 |
Gear Ratio | 4.286:1 | 4.185:1 | 4.207:1 | 4.206:1 | 4.206:1 |
Suction Inlet | 203/8 | 254/10 | 305/12 | 305/12 | 305/12 |
Discharge Inlet | 4Flange | 5Flange | 5Flange | 5Flange | 5Flange |
Lubrication | Forced& | Forced& | Forced& | Forced& | Forced& |
Max. Pressure | 27.2Mpa | 34.5Mpa | 34.5Mpa | 34.5Mpa | 35Mpa |
Overall Size(in) | 144*106*86 | 156*79*66 | 163*89*70 | 174*121*78 | 181*129*106 |
Weight(kg) | 9770 | 14500 | 18790 | 24572 | 24791 |
Export packing for Bomco F800 f1000 drilling rig mud pump
1.High quality products.
2.Fast delivery.
3.OEM services.
4.Perfect after-sale services.
1.How to get free samples?
Send your address,your telephone number,post code,and express account number to our mail box,and told us which samples you need and samples specification.
2.Can you produce products with my own brand?
Yes,we can offer OEM services.
3.Do you have any international certificate?
Yes,we have API, ISO and etc.
4.How long does my order take to be delivered?
It usually takes 5 to 30 days,which generally depends on the quantity of your order and our storage.
Support
Whether it’s a brand-new business or an established commercial enterprise if you need Mud Pump for your project. No worries, 365manufacturers.com is here to help with all kinds of Mud Pump Parts needs; we specialize in providing Mud Pump Fluid End Assembly, Mud Pump Liner, Mud Pump Piston Assembly, Mud Pump Valve Assembly, Mud Pump Crosshead Assembly, Mud Pump Crankshaft Assembly, Mud Pump Pinion Shaft Assembly, etc.
